Terex Manlift Specifications
Terex is a Westport, Connecticut company that specializes in producing in manufacturing construction equipment. machinery like manlifts, boom lifts and aerial lifts. These machines are designed to facilitate access to hard to reach areas, large equipment, buildings and roofs, amongst other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration or also called OSHA refers to a power-driven endless belt. This belt only moves in one direction and contains platforms, or steps or handholds that are connected to the unit in order to move workers from each floor.
TB85
Terex's TB85 man lift provides a max working height at 91 feet. The platform's max height reaches 85 feet, while the maximum width of the model is 8.5 feet. The TB85 has dimensions measuring 9 feet, 1-inch high and 9 inches wide by 36 feet. This particular model provides a reach of 70 feet. The TB85 has a boom angle above horizontal measuring 75 degrees and below horizontal measures at -14 degrees.
Terex TB100
The Terex TB100 man lift's maximum height is 106 feet and the platform's maximum height is 100 feet. The TB100 when stowed away, is about 8.5 feet wide by 9 feet high by 8 feet. The unit's maximum width is 8 feet, 1 1/2 inches. The boom angle below horizontal is -14 degrees and above horizontal is 75 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The TB110 has a maximum platform height of 100 feet and the unit's maximum working height overall measures at 116 feet. When stowed, this model is 8 feet wide x 9 feet, 4 inches high. The TB110 provides a maximum width of 8 feet and a horizontal reach of 67 feet. This model has a boom angle of 75 degrees above horizontal plus 10 degrees articulating. Below horizontal it is -14 degrees and it measures -105 degrees articulating.
